Helvar ACD-FD

Article number: HEL.ACD-FD

The ACD-FD dimmable AC driver is designed to be used with the trailing edge dimmable LED drivers and LED bulbs, as well as with other bulb types, creating now wirelessly controllable solution for applications designed for e.g. phase-cut control rotary switches. The product includes wireless Mymesh control for effortless wireless modification of the AC driver parameters.

Installation

ACD-FD LED is suited for built-in / box usage.

Technical

Electrical
85 VAC – 240 VAC
Control
Trailing-edge phase control
Dimensions/weight
40.8 x 36.7 x 15.9mm) / 16g
IP rating
IP20

Network

  • Mymesh 2.4GHz

    • Features

  • Optimal fit for trailing edge dimmable LED driver and LED bulb applications
  • Integrated surge protection up to 2 kV (L-GND)
  • Stand-by power < 0.3 W
  • Integrated antenna
  • Last gasp functionality (500 ms) after power off

    • Options

  • Max. output power 150 VA @ 230 VAC / 75 VA @ 120 VAC
  • Output current Max. 0.65 A
  • Max. allowed inrush current 10 A, 100 ms
