Chess sensors

remote switch

Article number: BLC.5023.001

The Mymesh BLC Remote Switch is a wireless switch to switch, dim or select a scene. It comes with a long-life battery and can be positioned everywhere as it is completely wireless.
The Remote Switch is used for different manual control options like switching, dimming, overrule and scenes selection for lighting fixtures equipped with Mymesh controllers or/and drivers drivers.

Installation

  • To install the switch, simply turn it on by holding both buttons for 5 seconds
  • After a 3 short beeps, the device is visible in the Mymesh app where it can be fully configured.
  • The switch has a special wall mount on the back.

    • Technical

    Electrical
    long life battery (10+year)
    Control
  • on/off
  • dimming / RGBW
  • scenes
    • Dimensions/weight
    80 x 80 x 15 mm / 75g
    IP rating
    IP54

    Network

  • Mymesh 2.4GHz

    • Features

  • On-the-fly (re) commissioning with a Mymesh BLE Gateway and Mymesh app for iPad
  • Connect to third-party back-office/ light management system

    • Options

  • multi-way functionality
