Chess GST controllers

GST - 0-10V

Article number: BLC.1804.001

The GST - 0-10V is a smart wireless 0-10V control module with 24VDC power supply for a 0-10V damper or valve actuator. With a GST - 0-10V you can easily control per zone an individual damper actuator, 2-way or 6-way valve actuator. Two 0-10V signals are available, one output and one input. Output for the controlled valve position and the input for the actual valve position. A wide range of HVAC applications is supported like VAV end devices and control valves for heating and cooling coils.

Installation

The GST - 0-10V module clips into an included bracket which is secured with one screw of blind rivet. Wieland GST pluggable electrical installation. Faster, smarter and safer. Mains powered single phase 230VAC (+/-10% 50Hz).

Technical

Electrical
100-240VAC, 50/60Hz
Control / Output
  • 0-10V
  • 3.0W max
    • Dimensions/weight
    118.35 x 49.42 x
    24.37 mm / 123g
    IP rating
    IP20

    Network

  • Mymesh V3 / 2.4GHz

    • Connections

  • Mains input
    connector: GST18I3L S1H SW
  • 24VDC / 0-10V
    connector: GST15I5L B1H W TB03

    • Features

  • easily control per
    zone an individual damper actuator, 2-way or 6-
    way valve actuator.
  • Two 0-10V signals are available, one output and
    one input.
  • 24VDC power supply for a
    0-10V damper or valve actuator
